GUNSTREET WIRING HARNESS - HSS 5 WAY - PERFECTO DE CASTRO SIGNATURE

Made just for the man himself this kit features some unique specs to turn your HSS Super Strat into something legendary!

Filter Circuit: Treble Bleed (Modern High pass Filter) Green Treble Bleed (Modern High Pass Filter) A treble bleed circuit incorporates an additional “bright” capacitor that maintains high-end as volume is decreased. A great circuit for guitarists who want to use their volume pot to roll off gain without losing any of their pickups’ sparkle or bite.

5 Way Switch Positions
* Push Pull Off
1 - Bridge Humbucker
2 - Bridge Coil 1 & Middle Single Coil Parallel
3 - Bridge Coil 2 & Neck Single Coil Parallel
4 - Middle Single Coil-Neck Single Coil
5 - Neck Single Coil
* Push Pull On
1 - Bridge Humbucker
2 - Bridge Coil 1
3 - Bridge Coil 2 & Neck Single Coil Parallel
4 - Bridge Coil 2-Neck Single Coil in Series
5 - Middle-Neck Single Coil in Series

Oak Super Switch Specs
Body cavity depth 1-3/8th" (34.93mm)
Mounting Screw Spacng1 5/8" (41.28mm)
Lever Stem (0.50x.190)

DHE Gunstreet Pot (Volume)
Taper Style: Custom Audio Taper
Knob type: 18 spline Coarse knurling
Shaft diameter: 3/8" (9.52mm)
Thread type: 3/8"-32
Threaded portion: 3/8" (9.52mm)
Required mounting hole diameter: 3/8" (9.52mm)
Value: 500k
Bourns Push pull (Tone)
Taper Style: Audio Taper
Knob type: 18 spline Coarse knurling
Shaft diameter: 3/8" (9.52mm)
Thread type: 3/8"-32
Threaded portion: 3/8" (9.52mm)
Required mounting hole diameter: 3/8" (9.52mm)
Value: 250k
Push Pull Require Depth: 1-1/16th”(26.99mm)
Capacitor Specs
Brand: CDE
Model: "Orange Drop"
Value .022uF
Rean Output Jack Specs
Mounting hole diameter 3/8" (9.52mm
) Thread 3/8 x 32
Threaded portion height 1/4" (6.35mm)
